Technical Specifications：
Wavelength 1470nm
Max Power 12W
Display/Control 7’HD vivid Touch-Screen
Aiming Beam 650nm<5mW
Fiber Connection 400um and 600um with standard SMA905 connector
Operating Modes Continuous Wave(CW)/Pulsed
Power Supply 18VDC 5A
Battery Capacity 3350mAh
Weight(without case) ≤2KG NW
Dimensions(L*W*H) 26cm(L)*12.5cm(W)*20cm(H)
The laser complies with the following standards：
IEC 60601-1:2005 +A1:2012
IEC 60601-1-2:2014
IEC 60601-2-22:2012
IEC 60825-1:2014

Optimal Clinical Configuration：
Superior cellular water absorption, gives 1470nm wavelength advanced vein ablation results at relatively low power settings, thus reducing thermal damage to surrounding tissues.Significant reduction of postoperative pain and side effects help to reach higher patient satisfaction that promote 1470nm lasers as the universal alternative to conventional 810/980nm lasers.Additionally, it has a very good effect on blood (no risk of bleeding).
Confirmed by clinical statistics, 1470nm's recommended power ranges from 5 to 10 watts.At settings of less than 12 Watts, tissue necrosis and damage can be controlled,therefore 1470nm 12Watts is a safer and cheaper configuration.
